TV Series

You are here：Home > Products > TV Series

Product Type

TV Series

PRODUCT FEATURES：

Low brightness and high grey scale that can show more than 14 bits grey scale under 300 nits brightness;

5000:1 high contrast ratio and 16.7M high color reproduction;

Redundancy design, back-up power and signal;

Die-casting aluminum, easy heat radiation, light weight high precision;

Front maintenance;

Silent without fans.

Parameters	TV Series
Pixel Pitch	1.0mm	1.2mm
LED Type	SMD0606	SMD0808
Cabinet Resolution	640×360
Cabinet Size	640×360×58mm
Pixels Calibration	Standard color and brightness calibration
Brightness	100cd~1,200cd/sqm
Grey Scale	12~16bit
Color Temp.	2,500K~10,000K
Drive Mode	Constant Current
Frame Frequency	50/60Hz, 120Hz
Refresh Rate	Standard Refresh Rate: ≤1,920, High Refresh: ≤3,840
Working Voltage	AC:110V~240V, 50/60Hz
Power Consumption	Average: 50~80W; Peak:130~180W
Lifetime(hours)	100,000h
Operating Temp.	-20℃~60℃
Storage Temp.	-25℃~60℃
Humidity Range	10%~90%, Non-condensing
Cabinet Weight	7.4kg/per cabinet

APPLICATION：

Meeting room、Control room、Show room、Shopping mall、Studio、Theater、Museum、Airport
